Saw-Spindle Moulder
B3 / B3 e-classic
Spindle moulder unit
Table opening (Ø) 190 mm
Spindle moulder-Ø max.
Spindle moulder guard 220 mm
Slot guard 275 mm
Spindle-Ø Standard 30 mm
Spindle shaft quick change system Option 1*) 32 / 35 / 50 mm
Spindle shaft quick change system Option 2*) 1 ¼ inch
constant rotation 3000/6000/8000/10000 min-1
Speed High velocity spindle 15000 min-1
Spindle height above table (Usable height) 100mm
Tilting of spindle *) 90° to 45°
* not available with e-classic
Only use spindle moulder tools,
• which have a max. authorised rotation speed higher than that of the spindle moulder
• which conform to DIN EN 847-1 or DIN EN 847-2 standards and
• which are marked with „MAN“!
4.7.2 Spindle moulder unit
4.8 Chip extraction
Saw unit aggregate Saw guard
Dust extraction outlet, Ø 120 mm 50 mm
Min. air speed 20 m/s 20 m/s
Min. vacuum 1824 Pa 953 Pa
Min. volume flow (at 20 m/s) 814 m³/h 141 m³/h
*) Standard = Saw guard / Option = Overhead saw guard
Spindle moulder unit
Spindle moulder
fence Slotting guard
Dust extraction outlet, Ø 120 mm 120 mm
Min. air speed 20 m/s 20 m/s
Min. vacuum 470 Pa 920 Pa
Min. volume flow (at 20 m/s) 362 m³/h 814 m³/h
*) Standard = Spindle moulder fence / Option = Slotting guard
