Saw-Spindle Moulder
B3 / B3 e-classic
5.3 Data plate
The data plate displays the following specifications:
• Model designation
• Machine number
• Voltage
• Phases
• Frequency
• Power
• Electricity
• Year of construction
• Manufacturer info
Fig. 5-15: Data plate
Setting up the machine
5.4 Safety devices
5.4.1 Safety break switches
Fig. 5-16: Main switch
Your machine is equipped with safety break switches.
Therefore, the saw blade or the spindle moulder unit can
only operate if the sliding cover is closed.
(The sliding cover and spindle door are closed and the
safety system is in the centre position)
!Break switch
"Spindle moulder door
