Hammer B3 - 4.2 Operation and Storage Conditions; 4.3 Electrical Connection; 4.4 Drive Motor

18
Saw-Spindle Moulder
B3 / B3 e-classic
Circular saw drive / Spindle moulder unit Alternating-current motor Three-phase current motor
Motor voltage 1x 230 V 3x 230 V / 3x 400 V
motor frequency 50/60 Hz 50/60 Hz
System of protection IP 55 IP 55
B3 Perform
Motor power S6-40 %
*
)
- 4 kW
Motor power S6-40 % - Option*) 3 kW 4 kW
B3 Winner/Winner comfort
Motor power S6-40 %
*
)
- 3 kW (3x 400 V)
Motor power S6-40 % - Option*) 3 kW 4 kW (3x 400 V)
B3 e-classic
Motor power S6-40 %
*
)
- 3 kW (3x 400 V)
Motor power S6-40 % - Option*) 3 kW -
Antriebsmotor Vorritzeinheit (Option)
Motor power S6-40 %
*
)
0,65 kW
**
)
0,65 kW
*) S6 = operation under load and intermittent service; 40% = relative operating factor
**) Max. cutting height: 2 mm
mains voltage according to specification plate ±10%
Safeguarding see circuit plan
Power supply cord (H07RN-F) 3x2,5 mm²/ 5x2,5 mm²
Triggering characteristic C (D*)
*) if starting up is slow, caused by large swinging masses
Specifications
4.2 Operation and storage conditions
Operating/room temperature +10° to +40°C
Storage temperature –10° to +50 °C
4.3 Electrical connection
4.4 Drive motor
The actual values can be found on the data plate.
