72
Saw-Spindle Moulder
B3 / B3 e-classic
Operation
10.5.6 Cutting wedges
1. General procedures for authorised working techni-
ques.
2. Only make wedges with a wedge cutting jig.
3. The width of the device has to measure at least
120 mm.
4. When machining, the saw blade has to be adjusted
marginally above the width of the workpiece.
5. Lower the guard onto the wedge cutting jig and
place a workpiece in the device.
6. Leave the wedge cutting jig placed against the paral-
lel cutting fence and move it with the device and the
workpiece right up to the splitter.
Fig. 10-8: Cutting wedges
