User Manual
Operation and Management
Page 4-30 (Rev. 4.1/ SW v1.60/ December 2006)
PHYSICAL LINK
The physical Link menu is used for enabling the operation of the physical link
(the MPEGoIP IN1 interface in this example), as well as for configuring its
parameters.
Physical Link 1-2-1-1-1
01 Operation DISABLE
02 IP Address 010.006.000.196
03 Subnet Mask 255.255.255.000
04 Default Gateway 010.006.000.001
Available options are
• Operation - for enabling or disabling this port
• IP Address - this MPEGoIP input port’s IP address
• Subnet Mask - this MPEGoIP input port’s Subnet Mask
• Default Gateway - the default gateway address
NOTE
The operator must enter valid IP addresses before the PVR 6000 can operate. If
one or more IP addresses are not entered correctly, the following message is
displayed: “Front-End Warning – IP Configuration Error”. This message
remains until all IP addresses are entered correctly.
OPERATION
The Operation menu is used for enabling or disabling this MPEGoIP input port.
Operation
1 ENABLE
2{ DISABLE
The available options are:
• ENABLE – enables the relevant MPEGoIP input (MPEGoIP IN1 in this
example)
• DISABLE - disables the relevant MPEGoIP input (MPEGoIP IN1 in this
example).
