User Manual
Overview
Page 1-2 (Rev. 4.1/ SW v1.60/ December 2006)
1.2. HIGHLIGHTS AND BENEFITS
The processing platform’s main features and options include:
• Variety of front-end options including DVB-S, DVB-S2, DVB-DSNG, G.703,
MPEG-over-IP and DS3-ATM
• DVB-S2 professional
• MPEG-over-IP (MPEGoIP) inputs supporting up to 44Mbps (SPTS and MPTS)
• Configurable De-Jitter delay
• Physical Link Redundancy
• Logical Source Redundancy
• FEC (Forward Error Correction) ProMPEG CoP3v2
• MPEGoIP output supporting up to 60Mbps
• IP-over-MPEG output up to 60 Mbps (MPE decapsulation)
• 1 or 2 L-Band inputs
• ASI transport stream input and output
• Service and PID Filtering over the ASI and IP outputs (dynamic and static
modes)
• DVB common interface (2 slots – 1 active simultaneously)
• SDI, AES/EBU and analogue outputs
• Up to 4 pairs of audio outputs supporting:
• Musicam
• Dolby Digital
®
AC-3 Pass-Through
• Dolby Digital
®
AC-3 2.0 Down Mixing
• Linear PCM Audio and Dolby-E Pass-Through (up to 3 outputs)
• Embedded audio in SDI and re-insertion of VBI
• VBI re-insertion in composite and SDI
• Genlock for high-end accurate frame synchronization
• Redundancy support, 2 GPI Dry Contact relays with separate control
• OSD (On-Screen Display) subtitling
• Various of management interfaces: Graphical front-panel, user-friendly Web-
Interface, command-line-interface (CLI) and SNMP
• SW permission mechanism enables future upgrade
