User Manual
PVR 6000 Control Interfaces
Page 3-2 (Rev. 4.1/ SW v1.60/ December 2006)
• Status LEDs
The two LEDs indicate WARNING and PWR/FAIL statuses, when both LEDs are lit
green the PVR 6000 status is OK. The WARNING LED (Green/Orange) indicates the
operational status. The PWR/FAIL LED (Green/Red) indicates the hardware status.
• Arrow Keys
The arrow keys include [Up], [Down], [Right], [Left]. The keys are used to
navigate between the different menu items and sub-menus. They are also used
to select and change parameters during setup and configuration procedures.
• [Enter] Key
Used to select or enter a configuration setup.
• [Esc] Key
Used to abort a configuration setup or to return to the menu's previous level.
• Short Cut Keys
Include the [F1]/[F2] buttons that are operator–programmable for
immediate activation of predefined procedures (in the future software
versions).
3.1.2. PVR 6000 Front Panel Screen
Types
The PVR 6000 display leads to the following five screen types:
• Menu Navigation screen
• Edit Menu screen
• Table Menu screen
• Edit Value screen
• Select Value screen
NOTE
The Front panel can display only up to four menu items at a time. When a menu
has more than four items, the first four are visible in the panel, followed by a
scroll icon [ ]. Additional items can be accessed using the [up]/[down]
arrows. To illustrate the difference between the two types of items, two types of
screen shots were used in this user manual: dark grey for the visible items and
light grey for the hidden ones.
