User Manual
Installation
Page 2-2 (Rev. 4.1/ SW v1.60/ December 2006)
2.3. INSTALLATION INSTRUCTIONS
This section explains the mechanical installation of the rack and PVR 6000
device.
2.3.1. Site Preparation
When installing the PVR 6000 in a standard 19" rack, verify that the rack is fully
prepared for the installation. To facilitate easy access during installation and
maintenance, leave sufficient space behind the rack.
The PVR 6000 must be installed within 1.5m (5 feet) from an easily accessible
grounded AC outlet, capable of furnishing the required supply voltage as
detailed in Section
2.5.1.
The use of a UPS (Uninterrupted Power Supply) and an AVR (Automated Voltage
Regulation) is highly recommended to ensure uninterrupted operation.
Ensure that a qualified electrician has installed the main power supply in
accordance with local power authority regulations. All powering should be wired
with an earth leakage in accordance with local regulations.
WARNING
TO AVOID ELECTROCUTION ENSURE THAT THE RACK HAS BEEN
CORRECTLY GROUNDED BEFORE SWITCHING ON THE PVR 6000 DEVICE.
WHEN REMOVING THE UNIT, REMOVE THE GROUNDED CONNECTION
ONLY AFTER THE UNIT IS SWITCHED OFF AND UNPLUGGED.
2.3.2. Mechanical Rack Installation
Due to its considerable weight, the device must be placed on a pair of rack-
slides, specially designed for this product (see Figure 2-1).
CAUTION
THE RACK-SLIDES MUST BE INSTALLED IN THE DEVICE’S DESIGNATED LOCATION WITHIN THE RACK,
SINCE THEY ARE INTENDED TO CARRY THE DEVICE’S WEIGHT. DO NOT RELY ONLY ON THE
DEVICE’S MOUNTING BRACKETS FOR SUPPORTING THE DEVICE’S WEIGHT. DOING SO MAY RESULT
IN DAMAGE TO THE RACK, DEVICE, AND OTHER MOUNTED DEVICES.
