User Manual
Installation
Page 2-6 (Rev. 4.1/ SW v1.60/ December 2006)
Figure 2-5 illustrates a general view of the device, when installed within the 19’’
rack.
Figure 2-5: Device Mounted on a Pair of Rack-Slides
A single pair of rack-slides can carry up to 50Kg (110 lbs). This allows saving
rack space by placing a number of rack-mount devices one upon the other (be
careful not to exceed the specified maximum weight).
WARNING
DO NOT APPLY OVER 50KG (110LBS) OF WEIGHT ON A SINGLE PAIR OF
RACK-SLIDES. DOING SO MAY RESULT IN COLLAPSING OF THE RACK-
SLIDES, SERIOUS INJURIES TO PERSONNEL, AND DAMAGE TO
EQUIPMENT.
