4.2.2. Satellite Receiver Modules
This section details the front panel menus that enable configuring of the DVB-S
DVB-S2 and DVB-DSNG receivers in an PVR 6000 front panel.
4.2.2.1. DVB-S Receiver Configuration
This section details the front panel menus that enable configuring the DVB-S
receiver in an PVR 6000 DVB-S front end device.
The following is the DVB-S
Receiver Configuration menu as displayed on the PVR 6000 front panel
screen:
Receiver
1-2-1
01 Frequency
1.068000 [GHz]
02 Symbol Rate
29.818000 [Mbaud]
03 FEC Rate
AUTOMATIC
04 Spectral Inversion
AUTOMATIC
05 LNB Power Supply
18V (HORIZONTAL)
06 LNB 22 KHz
OFF (Low Band)
07 Freq Drift Compensation
OFF
08 LNB L.O. Type
UNIVERSAL <9.75,...
09 Frequency Range
L BAND
10 Frequency Band Scan
OFF
To Next Page
