PVR 6000 Series
Professional Integrated Receiver Decoders
Page 1-23
FEATURE SPECIFICATIONS
DATA
• High speed data: RS-422 Up to 20 Mbps, RJ-45
(supported by PVR 6000 , PVR 6060 )
• IP Data Out (RJ-45): up to 60Mbps (MPE de-
capsulation)
1.7.3. Decoder Outputs
FEATURE SPECIFICATIONS
VIDEO
• Video Formats:
• PAL-B/G/I/M/N/D, NTSC, SECAM L/B/G/K1
• Russian SECAM D/K (composite video only
supported only by special order in PVR 6000 ,
PVR 6010and PVR 6060 )
• Decoding:
• 4:2:0 MP@ML (1.5 – 15 Mbps)
• 4:2:2 PP@ML (1.5 – 50 Mbps) (supported only
in IRD298x)
• Maximum TS decoding bit rate: 108Mbps
• Video resolution interpolation: Pan-scan, letter box
or Pass through
• Aspect ratios: 4:3/16:9
• Aspect ratio 14:9 by signaling over VBI video index
• Graphical processing (OSD): DVB subtitling, EBU
(Teletext) subtitling
• OSD only through monitoring output
• Genlock input and loop-through output (supported
only by IRD2962, IRD2963, IRD2981 and
IRD2992)
• Genlock Sync lock resolution: +/- 37nSec
