PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-21
Figure 4-4 displays the corresponding DVB-DSNG receiver parameters menu
(Web Management screen).
Figure 4-4: DVB-DSNG Receiver Parameters Menu Screen
FREQUENCY
The Frequency parameter must be set in accordance with the required satellite
transponder frequency. The frequency can be acquired from the satellite
transponder information.
In this example, the valid frequency range is between 0.95 and 2.15GHz.
Frequency
1.068000 [GHz]
<0.950000 - 2.150000>
To Next Page
