4.2.2.3. DVB-DSNG Module
This section details the front panel menus that enable configuring the DVB-
DSNG receiver in an PVR 6000 DVB-DSNG front end device.
The following is the DVB-DSNG Receiver Configuration menu as displayed on
the PVR 6000 front panel screen:
Receiver 1-2-1
01 Frequency 1.138000[GHz]
02 Symbol Rate 29.575707[Mbaud]
03 Modulations AUTOMATIC
04 Roll off AUTOMATIC
05 FEC Rate AUTOMATIC
06 Spectral Inversion AUTOMATIC
07 LNB Power Supply 18V(Horizontal)
08 LNB 22Hz OFF(Low Band)
09 Input Serial Source IN-A
10 Freq Drift Correction OFF
11 LNB L.O Type UNIVERSAL(9.75...
12 Frequency Range L BAND
13 Frequency Band Scan OFF
To Next Page
