PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-19
FREQUENCY RANGE
The Frequency Range menu is used for selecting the receiver’s active
frequency band.
Frequency Range
1 L BAND
2{ Ku BAND
3{ C BAND
Available frequency band options are:
• L BAND – selects the frequency range 0.950000 - 2.150000 GHz
• Ku BAND - selects the frequency range 3.200000 - 4.200000 GHz
• C BAND - selects the frequency range 10.700000 - 12.750000 GHz
FREQUENCY BAND SCAN
The Frequency Band Scan menu is used for mapping all the available
transmission frequencies received by the antenna. The symbol rate during the
scan is constant and must be set according to the satellite’s symbol rate. Upon
locating a valid DVB stream, the PVR 6000 logs the located frequency and
service name and outputs the log through the RS232 port (terminal) or through
Telnet.
Frequency Band Scan
1 OFF
2{ ON
The available options are:
• OFF – band scan is disabled
• ON – starts the band scan
