PVR 6000 Series
Professional Integrated Receiver Decoders
Page 1-5
1.5. MECHANICAL STRUCTURE
The PVR 6000 is housed in a rugged industrial enclosure, 1RU by 19" (rack
mount).
Figure 1-2: PVR 6000 Unit
1.5.1. Front Panel
The front panel allows control using a four-way touch pad, [Enter] key, [Esc]
key, and two programmable [F1]/[F2] keys. Operational commands and
parameters are displayed on a graphical LCD. The four-way touch pad allows
parameter modification and scrolling through the embedded VBI menus. Two
LEDs show the WARNING and PWR/FAIL status (see
Figure 1-3).
Figure 1-3: Front View of the IRD
