functionalities that are not available when using any PVR 6000 front panel
feature.
1.7. CHARACTERISTICS AND
SPECIFICATIONS
The following section provides with the PVR 6000 Characteristics and
specification.
1.7.1. Transport Stream Interface
Options
FEATURE SPECIFICATIONS
DVB-S
S
INGLE INPUT
• Interface - F-type 75Ω
• Constellation - QPSK
• Single L-band input
• Frequency range - 950-2150 MHz
• RF Input level: (-65) – (-25) dBm
• Symbol rate range - 1-45M Sym/s
• L-Band RF input with LNB control and loop-through
output
DVB-S
D
UAL INPUT
• Interface - F-type 75Ω
• Constellation - QPSK
• Dual L-band input
• Dual independent demodulators
• Manual selection between inputs
• Frequency range - 950-2150 MHz
• Symbol rate range - 1-45M Sym/s
• L-Band RF input with LNB control and loop-through
output
