User Manual
Overview
Page 1-20 (Rev. 4.1/ SW v1.60/ December 2006)
FEATURE SPECIFICATIONS
DVB-DSNG
S
INGLE INPUT
• Interface - F-type 75Ω
• Constellation – QPSK, 8PSK and 16QAM
• Single L-band input
• Frequency range - 950-2150 MHz
• Symbol rate range - 1-45M Sym/s
• L-Band RF input with LNB control and loop-through
output
DVB-S2
S
INGLE INPUT
• Applications - Broadcast services and DSNG EN 302
307
• Mode - Constant Coding and Modulation (CCM)
• Constellations: QPSK, 8PSK, 16APSK
• FEC frames: Normal (64800 bits), short (16200 bits)
• Roll-Off: 0.35, 0.25, 0.20
• Pilots – On, Off
• Frequency range: 950 MHz - 2150 MHz
• Symbol rate range - 64Ksym/s - 45Msym/s
• TS bit rate range - 128Kbps - 107Mbps
• 2 L-Band RF 75Ω inputs with LNB control
