User Manual
Operation and Management
Page 4-22 (Rev. 4.1/ SW v1.60/ December 2006)
The valid frequency range varies according to the selected band.
Table 4-3: Band Frequency Range
BAND MINIMUM FREQUENCY MAXIMUM FREQUENCY
Ku-Band
10.700000GHz 12.750000GHz
C-Band
3.200000GHz 4.200000GHz
L-Band
0.950000GHz 2.150000GHz
SYMBOL RATE
The Symbol Rate parameter must be set according to the satellite transponder
symbol rate. The Symbol Rate value can be acquired from the satellite
transponder information or can be calculated, with the bit rate information.
Symbol Rate
29.818000 [Mbaud]
<01.000000 - 45.000000>
Available values range from 01.000000 to 45.000000 Mbaud.
NOTE
It is important to input the accurate Symbol Rate down to the sixth digit after
the decimal point.
MODULATION
The Modulation menu allows setting the PVR 6000 receiver to the relevant
modulation method.
Modulation
1 AUTOMATIC
2{ DVBS-QPSK
3{ DVBS-8PSK
4{ DSNG-16QAM
ROLL- OFF
The Roll off menu is used for setting the receiver’s roll-off factor value
according to the roll-off factor of the transmitted signal.
