User Manual
Operation and Management
Page 4-80 (Rev. 4.1/ SW v1.60/ December 2006)
MONITOR ASPECT-RATIO
This parameter sets the intended image aspect ratio. It is used along with
Interpolation to determine the required Aspect Ratio Conversion.
NOTE
See 4.3.8.4.Appendix C for extensive details on how Monitor Aspect-Ratio
configuration affects the resulting image.
Monitor Aspect-Ratio
1{ VIDEO Source
2{ 16:9
3{ 16:9 Box
4 4:3
5{ 14:9
6{ 14:9 Box
The available options are:
• VIDEO Source – Monitor aspect ratio is determined by the video sequence
• 16:9 – Monitor aspect ratio is set to 16:9.
• 16:9 Box – Monitor aspect ratio is set to 16:9 with letter-box.
• 4:3 – Monitor aspect ratio is set to 4:3.
• 14:9 – This option will be supported in future PVR 6000 versions.
• 14:9 Box – This option will be supported in future PVR 6000 versions.
NOTE
The option VIDEO Source should not be selected along with choosing TV
MONITOR under Configuration
Æ
Video
Æ
VBI 1 / 2
Æ
WSS, since the two A/R may
contradict each other and cause unexpected results.
