PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-151
The MPEGoIP Input 1 Status parameters are:
• MAC Address – MPEGoIP IN1 port MAC address. The MAC address is a
unique, read-only address.
• Physical Link Status – current link status. The available options are:
• Down – Physical link is down
• Up – Physical link is up and connection is established
• 10Base-T, 100Base-T – IP Port data input rate
• Full – receiving in full duplex
• Half – receiving in half duplex
NOTE
MPEGoIP Input 2 Status parameters are identical to those of MPEGoIP Input
1 Status and provide information on MPEGoIP IN2 data.
GENERAL
The IP Receiver Status General menu as displayed on the PVR 6000 front panel
screen:
General 1-3-1-3
1 HW Revision 53
2 SW Version dd/mm/yy mj.mn 18/08/05 01.05
3 Configuration OK
4 Active Input 1
5 Encapsulation UDP
6 MPEG Packet Size 188
7 Rx Bitrate Current 33.792093 [MHz]
The General menu parameters are:
• HW Revision – FPGA hardware Revision
• SW Version – software date and software version
• Configuration – displays “OK” if receiver configuration is valid, or
“Mismatch” if it has inconsistencies
• Active Input - the actual
• Receive Mode – displays “UDP” or “RTP” according to the type of received
data
• MPEG Packet Size – size of received packets (in bytes). Can be either 188
or 204 bytes
• Rx Bitrate Current – current rate of received data (in MHz)
