Aspect Ratio Configuration Process
Page C-6 (Rev. 4.1/ SW v1.60/ December 2006)
OUTPUT DESCRIPTION
• No conversion
• Always displays
Normal picture on
16:9 and tall and
thin on the 4:3 TV
WSS –
• 16:9 Full Format
1110.0000.00.000
Can be output if
WSS is set as Video
Stream
• Conversion
horizontally up-
samples the central
portion of the
picture to fill the
720
WSS –
• 4:3 Full Format
0001.0000.000.000
Can be output if
WSS is set as
Monitor.
• 16:9 Full Format
1110.0000.000.000
can be output if
WSS is set as Video
Stream
• Conversion
vertically down-
stamps the picture
and applies black
bar to the top and
bottom of the
screen
WSS –
• 4:3 Full Format
0001.0000.000.00
0
can be output if
WSS is set as
Monitor
• 16:9 Letter Box
1101.0000.000.00
0
can be output is
WSS is set as
Video Stream
NOTE
With 16:9 L/B
signalling as auto
sense, 16:9 monitor
can convert the
picture to Normal
16:9
