Harmonic ProView PVR 6000 Series - Page 54

User Manual
Installation
Page 2-12 (Rev. 4.1/ SW v1.60/ December 2006)
Table 2-5 lists the Audio 3-4 breakout cable interface pin-out.
Table 2-5: Audio 3-4 Breakout Cable Pin-Out (Harmonic Inc. P/N
204346)
PIN FUNCTION PIN FUNCTION
1 Audio 4 XLR Right (+) 8 Audio 4 XLR Left Common
2 Audio 4 XLR Left (+) 10 Audio 3 XLR Left Common
3 Audio 3 XLR Right Common 11 Audio 4 XLR Right (-)
4 Audio 3 XLR Right (+) 12 Audio 4 XLR Left (-)
5 Audio 3 XLR Left (+) 14 Audio 3 XLR Right (-)
7 Audio 4 XLR Right Common 15 Audio 3 XLR Left (-)
Table 2-6 lists the AES/ABU balanced breakout cable pin-out.
Table 2-6: AES/EBU Balanced Breakout Cable Pin-Out (Harmonic Inc.
P/N 204345)
PIN FUNCTION PIN FUNCTION
1 AES/EBU 4 (+) 8 AES/EBU 3 Common
2 AES/EBU 3 (+) 10 AES/EBU 1 Common
3 AES/EBU 2 Common 11 AES/EBU 4 (-)
4 AES/EBU 2 (+) 12 AES/EBU 3 (-)
AES/EBU 1 (+) 14 AES/EBU 2 (-)
7 AES/EBU 4 Common 15 AES/EBU 1 (-)
