2-28 888-2629-200 10/6/10
WARNING: Disconnect primary power prior to servicing.
Section 2 Installation
Maxiva ULX COFDM Series
Figure 2-8 TB1 and TB2 Jumpers For Single Cabinet With 1 to 8 PA Modules
Top View of Back of PA Cabinet, Jumpered for 208 to 240 VAC Delta or WYE
TB1
1234567891011
Ground
Block
AC Power
Entrance
AC Power
Entrance
MOV
Board
12
Top View of Back of PA Cabinet, Jumpered for 380 to 415 VAC WYE
TB1
1234567891011
Ground
Block
AC Power
Entrance
AC Power
Entrance
MOV
Board
12
L3NL2L1
L3NL2L1
