Functions and outputs
192 I3031-14.0 HBM: public Quantum
X
Analog output (1)
Nc
1 or 5
2 or 6
GND 1 or GND 3
3 or 7
4 or 8
Gnd 2 or Gnd 4
U1
Ground 1
1
2
3
4
5
6
7
8
Note:
GND 1: Terminals 1 and 2
GND 2: Terminals 3 and 4
GND 3: Terminals 5 and 6
GND 4: Terminals 7 and 8
