Connecting individual QuantumX modules
Quantum
X
I3031-14.0 HBM: public 71
S On the “Alternate Configuration” tab, select the
“User-defined” option and enter your data in the “IP
address” and “Subnet mask” lines.
Example:
Setting the IP address manually – PC side
Settings IP address Subnet mask
Module before 169.1.1.22 255.255.255.0
PC / notebook before 172.21.108.51 255.255.248.0
PC / notebook after 169.1.1.1 255.255.255.0
