11 Commissioning
108 PHLOX II Ignition Control System
Analogue external common ignition energy set point offset
To setup an analogue common ignition energy set point offset, perform following configu-
ration:
- Setup the sensor IgnitionEnergyOffset [Par. 2901].
- Par. 5947 = 1
- Par. 5948 = 0
Digital external common ignition energy setpoint offset
To set up a digital common ignition energy set point offset, perform the following configu-
ration:
- Set the switch functions SwitchIgnEgyOffsInc [Par. 2813] and
SwitchIgnEgyOffsDec [Par. 2814]. Using recommended a tristate switch
and only one digital input for this purpose are recommended
- Par. 5947 = 1
- Par. 5948 = 1
- Par. 1947 = minimal digital ignition energy setpoint offset
- Par. 1948 = maximal digital ignition energy setpoint offset
The actual active digital ignition energy set point offset is stored in a non-
volatile memory after each modification and is used as the initial offset value
after, for example, the control unit .
11.9.3 Cylinder specific ignition energy correction
To setup a cylinder specific correction of the ignition energy, perform following configuration:
- Set all the cylinder specific ignition energy corrections by configuring Par. 1950-1965.
These terms will be added to the common ignition energy set point, and as a result may be
positive or negative. In any case, the ignition energy set point of each cylinder will be be-
tween 0 and 31.
- Par. 5950 = 1
