10 Configuring the control’s inputs and outputs
PHLOX - Ignition Control System 71
8801 DigitalOut1:Param(1) 3909
8802 DigitalOut1:Param(2) 3909
8803 DigitalOut1:Param(3) 3909
8804 DigitalOut1:Param(4) 3909
8805 DigitalOut1:Param(5) 3909
8806 DigitalOut1:Param(6) 3909
8807 DigitalOut1:Param(7) 3909
8810 DigitalOut2:Param(0) 3801
8811 DigitalOut2:Param(1) 3800
8960 DigitalOut1:Mask(0) FFFF Hex
8961 DigitalOut1:Mask(1) 0001 Hex
8962 DigitalOut1:Mask(2) 0002 Hex
8963 DigitalOut1:Mask(3) 0004 Hex
8964 DigitalOut1:Mask(4) 0008 Hex
8965 DigitalOut1:Mask(5) 0010 Hex
8966 DigitalOut1:Mask(6) 0020 Hex
8967 DigitalOut1:Mask(7) 0040 Hex
10.5.2 Error monitoring of digital outputs
Digital outputs are monitored with cable breaks, short circuits and overcurrents. Moni-
toring and parameterising of digital outputs is heavily dependent on the electric charac-
teristics of the connected loads.
Monitoring is activated with the parameter
51x0 DOPWMy_SupviseOn monitoring of output
The electrical characteristics of the connected load require a short interruption of output
monitoring whenever output level changes. This delay time is set with the following pa-
rameter:
111x0 DOPWMy_DelayTime delay time after edge change
The following table provides an overview of possible errors:
Signal short circuit to earth
- Governor has detected a short circuit to earth.
error message appears alone
Check wiring and connected loads.
Short circuit to supply voltage
- Governor has detected a short circuit to supply voltage.
error message appears alone
Check wiring and connected loads.
Table 23: Possible digital sensor errors
