11 Commissioning
78 PHLOX II Ignition Control System
each cylinder fires 2 times per cycle (wasted spark). Very often 2 cylinders are
firing simultaneously. Consequently Phlox functions are limited: no cylinder
individual ignition angle and energy offsets, no knock spark retards, secondary
diagnostics (secondary open / short, spark duration low / high) only during ig-
nition test possible and not while engine is running.
Pick-up configuration very similar to measuring method 3.
11.3.3 Measuring Method 3 (Software Version AAA-B0-DDD)
11.3.1 Measuring Method 1 (Software Versions AAA-B1/2-DDD)
If the measuring wheel has a single tooth gap firmware variant
B1 must be used.
If the measuring wheel has a double tooth gap, firmware variant
B2 must be used.
In both cases the setup of pick-up and measuring wheel still is
exactly identical.
Crankshaft pick-up setup
Activate Pick-up:
Par. 4001 = 0 (Pick-up is on crankshaft)
Par. 4002 = 1
Configure pick-up type according to used pick-up:
Par. 4020 = 0 for Hall Pick-ups.
Par. 4020 = 1 for inductive (magnetic) pick-up.
Hall crankshaft pick-up setup
This paragraph concerns only Hall pick-ups
Configure pick-up power supply according to pick-up specification
Par. 4022 = 0 to setup a 12V pick-up power supply
Par. 4022 = 1 to setup a 5V pick-up power supply
