6 Installation
30 PHLOX II Ignition Control System
6.3.5 Analogue input
Sensor cables for:
Analog input, configurable 0-5V or 4-20mA:
Terminal 18 (AI_SIG_0V), Terminal 17 (AI_SIG(C/V)),
Terminal 4 (AI_POW(5VR/24V)), Terminal 5 (AI_POW_0V), Terminal 6
(AI_SHIELD)
Terminal of differential AI for sensors with analogue signal (setpoint-unit, pres-
sure-sensor, temperature-sensor etc.) or from analogue output of other ECU.
Protected power-supply for sensor is including.
AI terminal is configurable by software for work with:
analogue current signal 4 … 20 mA;
analogue voltage signal 0.5 … 4.5 V.
Configurable by software for support of sensor with power supply out:
- 5 V (by use of potentiometer as settpoint-unit) or +Bat.
Signal in voltage-mode 0.5 ... 4.5V, signal in current-mode 4 ... 20 mA
PHLOX, wire-terminals in control cabinet and sensor or other ECU
For sensor with voltage-signal: twisted 3 core shielded cable
For sensor with current-signal: twisted 2 core shielded cable
Cable shielding should be terminated by PHLOX-Terminal “Shield” only.
For sensor:
Insulation required between signals and metal-case (or other external networks) of sensor.
For customer ECU:
DC-entcoupling between signals and PE (frame) by customer ECU is required.
Part of PHLOX II input cable harness
