9 Inputs and outputs
PHLOX II Ignition Control System 59
9.7 Digital outputs
The PHLOX II control unit feature a maximum of two digital outputs. The required pa-
rameter settings for the assignment are described in chapter  9.1 Selectable in-
puts/outputs.
Input
Designation
Terminal
Type
Power
(max.)
Digital output 1
*
P1
16
low side
1 A
Digital output 2
*
P2
3
low side
1 A
Table 19: PHLOX II: Digital outputs
*
Configurable as digital input/output or PWM input/output
