5 Sensors
12 PHLOX II Ignition Control System
5 Sensors
5.1 Pick-up sensors in general
Pick-up terminals with power supply for sensors 2×
Each pick-up terminal is configurable for several types of pick-up sensor:
- inductive pick-up shaft position sensor
- Hall effect pick-up shaft position sensor, supply voltage 12 V;
- Hall effect pick-up shaft position sensor, supply voltage 5 V;
- discrete output or open contact
Analogue input with power supply for sensor 1×
Analogue input is configurable as:
- voltage-input (Rin < 300 kOm) for signal 0 … 5 V
- current-input (Rin < 220 Om) for signal 0 … 25 mA
Digital input/output, PWM compatible 2×
Each DIO-terminal is configurable as:
- low-side DI or low-side PWM-In, with or without internal pull-up
- high-side DI or high-side PWM-In, with or without internal pull-down
- switch-input “up / down“;
- low-side DO (up to 0,5A) or low-side PWM-Out, with or without internal pull-up
