9 Inputs and outputs
PHLOX II Ignition Control System 57
- Firmware with support for only 1 pick-up (camshaft trigger disk)
Connection
name
Terminal
Configuration
parameters
Configuration
Index
25
4025 PickUpInductivOrHall
0 = Hall pick-up
1 = inductive pick-up
4026 TrigDiskBoreOrTeeth
Indicates if the trigger disk consists
of holes or teeth
0 = Teeth
1 = Holes
4027 HallPUSupply5Vor12V
Selects the pick-up power supply on
pin 13
0 = 12V
1 = 5V
4028 HallPUPolInvOrHzm
Indicates whether the pick-up polari-
ty is similar to Heinzmann pick-ups
or inverted
0 = Hzm standard (low over tooth)
1 = Inverted (low over gap)
4029 HallPUTrigInvOrHzm
Selects trigger flank used either as
Heinzmann standard or inverse
0 = Hzm standard (the flank used is
the one at the begin of tooth / hole)
1 = Inverse (the flank used is the one
at the end of tooth / hole)
9.3 Analogue input
PHLOX II is equipped with 1 analogue input which can be configured for current or voltage
Connection
name
Terminal
Configuration
parameters
Configuration
AI
17
5510 AIWithSensorSupply
0 = deactivates control of sensor supply
1 = activates control of sensor supply
5511 AISupply24VOr5V
Selects sensor supply used (pin 4)
0 = 5V
1 = 24V
5512 AIVoltOrCurrent
Selects sensor type (voltage or current)
0 = Current (0 ... 25 mA)
1 = Voltage (0 ... 5 V)
