9 Inputs and outputs

56 PHLOX II Ignition Control System

Connection

name

Terminal

Configuration

parameters

Configuration

4027 HallCamSupply5Vor12V

Only Hall pick-ups (Par. 4025 = 0):

selects the pick-up power supply on

pin 13

0 = 12V

1 = 5V

4028 HallCamPolInvOrHzm

Only Hall pick-ups (Par. 4025 = 0):

indicates whether the pick-up polar-

ity is similar to Heinzmann pick-ups

or inverted

0 = Hzm standard (low over tooth)

1 = Inverted (low over gap)

4029 HallCamTrigInvOrHzm

Only Hall pick-ups (Par. 4025 = 0):

selects trigger flank used either as

Heinzmann standard or inverse

0 = Hzm standard (the flank used is

the one at the begin of tooth / hole)

1 = Inverse (the flank used is the

one at the end of tooth / hole)

Table 15: PHLOX II: pick-up inputs
