14 Error Handling
PHLOX - Ignition Control System 199
Pick-up power supply short circuit to supply voltage
- The measured pick-up power supply voltage is greater the high error
threshold
Only error message
Check cable to pick-up
Table 27: Possible errors speed pick-ups
11.3 Pick-up Configuration
14.4.2 Camshaft index sensor
3003 ErrPickUp / ErrPickUpIndex
Camshaft index sensor has failed or cable to camshaft index sensor is
faulty
- For a certain interval no signal is measured (monitoring only when 2000
Speed > 256 StartSpeed2).
- Crankshaft gap has been detected but camshaft index sensor does not
transmit a signal.
On engine start: emergency shutdown, if test procedure is not allowed,
otherwise attempt to synchronise.
With running engine: only error message
Check distance between camshaft index sensor and gear rim.
Check cable to camshaft index sensor.
Check camshaft index sensor, replace if necessary.
Camshaft index sensor has been mounted in wrong direction of magnet-
ization
- Monitored only if function 4016 CheckPickUpDirection is active.
error message only
Check preferred direction of camshaft index sensor.
Check configuration of preferred direction.
Camshaftindex power supply short circuit to earth
- The measured camshaftindex power supply voltage is below the lower
error threshold
Only error message
