14 Error Handling
PHLOX - Ignition Control System 215
14.4.16 Ignition errors
13050 ErrIgnitionCyl1 13051 ErrIgnitionCyl2
13052 ErrIgnitionCyl3 13053 ErrIgnitionCyl4
13054 ErrIgnitionCyl5 13055 ErrIgnitionCyl6
13056 ErrIgnitionCyl7 13057 ErrIgnitionCyl8
13058 ErrIgnitionCyl9 13059 ErrIgnitionCyl10
13060 ErrIgnitionCyl11 13061 ErrIgnitionCyl12
13062 ErrIgnitionCyl13 13063 ErrIgnitionCyl14
13064 ErrIgnitionCyl15 13065 ErrIgnitionCyl16
Error
Meaning
0
Ignition capacitor charge error
- The energy level set point has not been reached before ignition
 Error message only
 Check pick-up configuration
 Check control unit power supply
 Check min. and max. charge current settings (Par.1950, 1951)
 Check cylinder individual timing offsets
1
Primary short
- Short circuit detected on the primary ignition coil circuit
 Error message only
 Check wiring and connected coils
 Check coil polarity (inversion + / -)
2
Primary open
- Open circuit detected on the primary ignition coil circuit
 Error message only
 Check wiring and connected coils
3
Secondary short
- Short circuit detected on the secondary ignition coil circuit
 Error message only
 Check spark plug
 Check high voltage cable
 Check ignition coil
 Try reduce energy set point
4
Secondary open
- Open circuit detected on the secondary ignition coil circuit
 Error message only
 Check spark plug
