Heinzmann PHLOX II IC-08 User Manual

14 Error Handling
PHLOX - Ignition Control System 213
Error
Meaning
1
Exception error
- The control device reports an internal computing error.
 Emergency shutdown.
 Write down parameters 3191 to 3199.
 Restart governor by a reset and inform HEINZMANN.
2
Error in cyclical program test
- Checksum calculated by the program does not correspond to the memo-
rized checksum.
 Emergency shutdown.
 Write down parameters 3191 to 3199.
 Restart governor via a reset .and inform HEINZMANN.
3
Error in cyclical RAM test
- The cyclical RAM test reports an error.
 Emergency shutdown.
 Write down parameters 3191 to 3199.
 Restart governor via a reset and inform HEINZMANN.
4
Overflow of error memory
- The memory space reserved for errors is full.
 Error message only
 New errors are no longer memorized in the error memory.
 The error memory must be cleared.
5
Error index too great
- Attempt to set an error whose parameter does not exist.
 Error message only
 Restart governor by a reset and inform HEINZMANN.
Table 44: Possible errors: Internal computing error
14.4.15 Digital and PWM outputs
13000 ErrDigitalOut1
13001 ErrDigitalOut2
Error
Meaning
0
Signal short circuit to earth
Cable broken (only for low-side outputs)
- Governor has detected a short circuit to earth or a broken cable.
 Error message only
 Check wiring and connected loads.
