Heinzmann PHLOX II IC-08 User Manual

13 Parameter Description
186 PHLOX II Ignition Control System
13.5 Curves
7700
PUTrgLev:Speed(x)
Firmware versions AAA.B1/2.DDD
up to
7724
Level: 4
Range: 0 ... 4000 1/min
Page(s):
Speed-supporting points of pick-up trigger level curve (mag-
netic / inductive pick-ups only)
7710
PUTrgLev:Volt(x)
Firmware versions AAA.B1/2.DDD
up to
7734
Level: 4
Range: 0,050 ... 5.000 V
Page(s):
Speed-dependent trigger level values of pick-up trigger level
curve (for magnetic /inductive pick-ups only )
7720
PUTrgLev:Speed(x)
Firmware versions AAA.B0.DDD
up to
7724
Level: 4
Range: 0 ... 4000 1/min
Page(s):
Speed-supporting points of pick-up trigger level curve (mag-
netic / inductive pick-ups only)
7730
PUTrgLev:Volt(x)
Firmware versions AAA.B0.DDD
up to
7734
Level: 4
Range: 0,050 ... 5.000 V
Page(s):
Speed-dependent trigger level values of pick-up trigger level
curve (for magnetic /inductive pick-ups only)
7720
CamIxTrgLev:Speed(x)
Firmware versions AAA.B1/2.DDD
up to
7724
Level: 4
Range: 0 ... 4000 1/min
Page(s):
Speed-supporting points of camshaft index pick-up trigger
level curve (magnetic / inductive pick-ups only)
7730
CamIxTrgLev:Volt(x)
Firmware versions AAA.B1/2.DDD
up to
7734
Level: 4
Range: 0,050 ... 5.000 V
Page(s):
Speed-dependent trigger level values of camshaft index pick-
up trigger level curve (for magnetic /inductive pick-ups only)
8200
MnfldPToPow:Press(x)
up to
8209
Level: 4
Range: 0,00 ... 5.00 bar
Page(s):
Manifold pressure supporting points of manifold pressure to
engine power interpolation curve
8210
MnfldPToPow:Power(x)
up to
8219
Level: 4
Range: 0,0 ... 100,0 %
Page(s):
Engine power values of manifold pressure to engine power
interpolation curve
8800
DigitalOut1:Param(x)
up to
8807
Level: 6
Range: -29999 ... 29999
Function assignment for multiple assignment to digital output
1
