6 Installation
PHLOX II Ignition Control System 23
6.2.2 PHLOX II - IC8/12/16 – Pin assignment Connector X2
Pin Nr.:
Signal Name
Application
1
“CHANNEL_1“
“+“ Ignition coil Cyl. 1*
2
“CHANNEL_2“
“+“ Ignition coil Cyl. 2*
3
“CHANNEL_3“
“+“ Ignition coil Cyl. 3*
6
“CHANNEL_4“
“+“ Ignition coil Cyl. 4*
5
“CHANNEL_5“
“+“ Ignition coil Cyl. 5*
4
“CHANNEL_6“
“+“ Ignition coil Cyl. 6*
8
“CHANNEL_7“
“+“ Ignition coil Cyl. 7*
7
“CHANNEL_8“
“+“ Ignition coil Cyl. 8*
13
“CHANNEL_9“
“+“ Ignition coil Cyl. 9*
12
“CHANNEL_10“
“+“ Ignition coil Cyl. 10*
11
“CHANNEL_11“
“+“ Ignition coil Cyl. 11*
10
“CHANNEL_12“
“+“ Ignition coil Cyl. 12*
15
“CHANNEL_13“
“+“ Ignition coil Cyl. 13*
14
“CHANNEL_14“
“+“ Ignition coil Cyl. 14*
16
“CHANNEL_15“
“+“ Ignition coil Cyl. 15*
17
“CHANNEL_16“
“+“ Ignition coil Cyl. 16*
25
“JL“
“-“ Ignition coils rail Bank A / Motor ground
24
“JL“
23
“JL“
22
“JR“
“-“ Ignition coils rail Bank B / Motor ground
21
“JR“
9
“JR“
20
“J“
Motorground
Hardwired
ignition stop
19
“G“
Shutdown-wire
18
-
Not used
(* Ignition order configurable by software
Table 5: Connector X2
Mind order of pin assignment when connecting.
Pin number does not always correspond to channal number.
