14 Error Handling
204 PHLOX II Ignition Control System
14.4.5 Ignition
3035 ErrIgnitionTiming
Error
Meaning
0
1
Overlapping of ignition
- the ignition for the current cylinder starts before the end of ignition of cyl-
inder before.
 Emergency shutdown.
 Check cylinder individual ignition angle offsets
Table 31: Possible errors: Ignition timing
14.4.6 Synchronisation
3036 ErrSynchronisation
Error
Meaning
0
Synchronising lost with running engine
- Monitoring only as long as 2000 Speed > 256 StartSpeed2
 ignition is turned off, attempt at renewed synchronisation
 Check distance of pick-up from sensing wheel.
 Check sensing wheel.
 Check speed pick-up
 Check parameter 6 GapRatio.
1
Distance between gap and index sensor is too great
- Monitoring only during engine start.
- Monitored only if function 4007 CheckGapToIndexDist is active.
 error message only
 Check configuration of sensor positions.
2
Wrong number of teeth on active crankshaft impulse transmitter
- The number of measured teeth between two gaps following one after the
other does not correspond to the pre-set number of teeth.
 Ignition is turned off, attempt at renewed synchronisation
 Check distance of pick-up from sensing wheel.
 Check sensing wheel.
 Check speed pick-up.
 Check parameter 6 GapRatio.
3
Synchronization not possible
- Synchronization was not successful within 10 seconds after attempted en-
