11 Commissioning
PHLOX - Ignition Control System 77
11.3 Pick-up Configuration
A pick-up / index configuration will only be activated after saving all parame-
ters and resetting the control unit
3 main measuring methods are available
Measuring Method 1 Measuring Method 2 Measuring Method 3
Figure 12: Pick-up configuration
These measuring methods are supported by the software versions AAA-B0/1/2-DDD
Additional firmware versions have been released to fulfil special requirements but are
not described in all details in the following.
o AAA-B4-DDD
2 redundant pick-ups on a measuring wheel with single / double tooth gap in-
stalled on engine camshaft. Note the first active pick-up is pick-up 1. If pick-
up 1 fails, Phlox will use pick-up2 as backup. Time to switch over is very short
but ignition will be stopped until pick-up2 is synchronized with the measuring
wheel (gap detected).
Very similar to measuring method 2 but with 2 pick-ups.
11.3.2 Measuring Method 2 (Software Version AAA-B1/2-DDD)
o AAA-B7-DDD
1 pick-up on a measuring wheel with single / double tooth gap installed on a
2-strokes engine crankshaft. Range of TDC angles is 0-360° instead of 0-720°
Very similar to measuring method 1 but without cam index.
11.3.1 Measuring Method 1 (Software Versions AAA-B1/2-DDD)
o AAA-B8-DDD
1 pick-up on a trigger disk n+1 installed on the engine crankshaft. In that case,
Crankshaft:
- measuring wheel with single / double tooth gap
Camshaft:
- trigger disc n+1
Camshaft:
- measuring pin
Camshaft:
- measuring wheel with single / double tooth gap
