8 Switching functions
48 PHLOX II Ignition Control System
01 = Ignition Timing Offset Increase (at edge
change) (if Par. 5917 = 1 and Par. 5918 = 1)
01 = Ignition Timing Offset Decrease (at edge
change) (if Par. 5917 = 1 and Par. 5918 = 1)
01 = Ignition Energy Offset Increase (at edge
change) (if Par. 5947 = 1 and Par. 5948 = 1)
01 = Ignition Energy Offset Decrease (at edge
change) (if Par. 5947 = 1 and Par. 5948 = 1)
01 = current errors are cleared (at edge change)
0 = Ignition Timing Map 1 active (if Par. 5910 = 1)
1 = Ignition Timing Map 2 active (if Par. 5910 = 1)
Table 12: Switching functions
8.1.1 Ignition stop
For ignition stops, 4810 StopImpulseOrSwitch it can be determined whether the ignition
stop is to remain active as long as the request itself also remains active, or whether a
single switching pulse shall be sufficient to activate the ignition stop. In the latter case,
the ignition stop request will only end when the engine has completely stopped, i.e.
when speed 0 is recognized.
4810 StopImpulseOrSwitch = 0 ignition stop is active only as long as the stop
command is coming in
4810 StopImpulseOrSwitch = 1 ignition stop is activated by a single switching
pulse until the engine stops
8.2 Assignment of digital inputs
A digital input can be assigned to a switching function by entering the number of the digi-
tal input in the assignment parameter of the respective function, starting from 810 Funct...
The number of digital inputs always runs from 1 to the maximum number for that particu-
lar control device.
These assignment parameters are parallel to the indication parameters for switching func-
tions that start from 2810 Switch....
Assignment of the value 0 means that the switching function in question has not been allo-
cated to a digital input. Such a switching function will always have the value 0, except
when it is received via a communications module.
