13 Parameter Description
120 PHLOX II Ignition Control System
13.2 Parameters
1
TriggerDisk
Firmware versions AAA.B0.DDD
Level: 4
Range: 2 ... 12 +1
Page(s):
Type of trigger disk installed on camshaft (x+1 indexes)
1
TeethPick-up
Firmware versions AAA.B1/2.DDD
Level: 4
Range: 30 ... 255
Page(s):
Number of teeth on the measuring wheel
3
PickUpToRefIndex
Firmware versions AAA.B0.DDD
Level: 4
Range: 0 ... 720 °crank
Page(s):
Distance of pick-up sensor from the reference index on the
trigger disk
3
SensorToGapPickUp
Firmware versions AAA.B1/2.DDD
Level: 4
Range: 0 ... 720 °crank
Page(s):
Distance of pick-up sensor from the reference mark on the
crankshaft / camshaft wheel
5
SensorToCamIndex
Firmware versions AAA.B1/2.DDD
Level: 4
Range: 0 ... 720 °crank
Page(s):
Distance of camshaft index sensor from the reference mark on
the camshaft wheel
6
GapRatio
Firmware versions AAA.B1/2.DDD
Level: 4
Range: 1.10 ... 1.90
Page(s):
Ratio for determination of the synchronising mark
multiplier for the time between two teeth
7
GapToCamIndexMax
Firmware versions AAA.B1/2.DDD
Level: 4
Range: 0 ... 720 °crank
Page(s):
Allowed distance to camshaft index
9
EngineConfiguration
Level: 4
Range: 0 ... 13
Page(s):
Configuration of cylinder number and firing sequence
21
SpeedOver
Level: 4
Range: 0 ... 4000 1/min
Speed threshold for ignition stop in case of overspeed
