Heinzmann PHLOX II IC-08 User Manual

14 Error Handling
210 PHLOX II Ignition Control System
Error
Meaning
11
Error of -1.5V reference Voltage too high
- Internal -1.5V reference voltage is too high.
 only error message
Table 39: Possible errors: Supply voltage
14.4.11 Internal temperature measurement
3077 ErrIntTempAddModul1
3078 ErrIntTempAddModul2
3079 ErrIntTempDCDCAir
3082 ErrIntTempCaseOutput
3084 ErrIntTempAirOutput
Error
Meaning
0
Signal short circuit to earth
- The measuring value of the respective input value is below the lower error
threshold.
  Error message.
1
Signal short circuit to supply voltage
- The measuring value of the respective input value is greater the upper
error threshold.
  Error message
5
Internal temperature is too high
- Internal temperature is higher that 120 °C for more than 1 second.
 Warning
6
Internal temperature is extremely high
- Internal temperature is higher that 135 °C for more than 1 second.
 Emergency shutdown
Table 40: Possible errors: Internal temperature measurement
3080 ErrIntTempDCDCMosfet
3081 ErrIntTempDCDCTrafo
