13 Parameter Description
136 PHLOX II Ignition Control System
13.3 Measurements
2000
Speed
Level: 1
Range: 0 ... 4000 1/min
Page(s):
Current speed
2003
SpeedPickUpValue
Firmware versions AAA.B1/2.DDD
Level: 1
Range: 0 ... 4000 1/min
Page(s):
Unfiltered speed as read by speed pick-up
2005
ActivePick-up
Firmware versions AAA.B1/2.DDD
Level: 1
Range: 0 ... 2
Page(s):
Active pick-up check
2006
PMMErrorCode
Firmware versions AAA.B1/2.DDD
Level: 1
Range: 0000 ... FFFF Hex
Page(s):
Error code relating to recognition of tooth gap
2007
SynchronToGap
Level: 1
Range: 0 ... 1
Page(s):
Message showing that trigger disk / tooth gap has been recog-
nised
2008
TryToFindGap
Firmware versions AAA.B1/2.DDD
Level: 1
Range: 0 ... 1
Page(s):
Message indicating that tooth gap is being searched for
(in case of lost camshaft index sensor signal)
2009
SpeedPickUpValue
Firmware versions AAA.B0.DDD
Level: 1
Range: 0 ... 4000 1/min
Page(s):
Unfiltered speed as read by speed pick-up
2009
SpeedCamIndex
Firmware versions AAA.B1/2.DDD
Level: 1
Range: 0 ... 4000 1/min
Page(s):
Current speed value from camshaft index sensor
2010
GapToCamIndex
Firmware versions AAA.B1/2.DDD
Level: 1
Range: 0 ... 720 °crank
Distance in degrees of crankshaft angle between synchronisa-
tion gap and camshaft index
