Heinzmann PHLOX II IC-08 User Manual

6 Installation
PHLOX II Ignition Control System 31
Connection to customer ECU inside control-cabinet and use of common power –supply.
Connection to sensor with voltage-sygnal
Connection to sensor with current-signal
AI_SIG_0V
T. 17
Sensor
with output-signal 0 ... 5V
PHLOX II
T. 18
Cabinet terminals
U
P
PE
T. 5
T. 6
Control-cabinet
AI_SIG_(C/V)
AI_POW(5VR/24V)
AI_SHIELD
AI_POW_0V
T. 4
PE
PE by engine-block
AI_SIG_0V
T. 17
Sensor
with output-signal 4 ... 20 mA
PHLOX II
T. 18
Cabinet terminals
I
P
PE
T. 5
T. 6
Control-cabinet
AI_SIG_(C/V)
AI_POW(5VR/24V)
AI_SHIELD
AI_POW_0V
T. 4
PE
PE by engine-block
AI_SIG_0V
T. 17
PHLOX II
T. 18
Cabinet terminals
PE
T. 5
T. 6
Control-cabinet
AI_SIG_(C/V)
AI_POW(5VR/24V)
AI_SHIELD
AI_POW_0V
T. 4
T. 15
T. 1
T. 14
T. 2
Power
supply
Analog
output
Power-supply input
Customer ECU
PE
