11 Commissioning
110 PHLOX II Ignition Control System
In the ignition test window, the measured ignition energy, the measured spark duration and
the diagnostic messages will be displayed.
In addition to the test mode, it is recommended to first crank the engine without fuel and to
verify the correct ignition angles of all cylinders using a stroboscope. If the measured igni-
tion angle does not match with the setup (Par. 13550-13565), verify the engine firing order
configuration (chapter 1) and the pick-up configuration (chapter 2). Note that modification
on engine or pick-up configuration will only be active after saving all parameters and reset-
ting the control unit.
