6 Installation

PHLOX II Ignition Control System 33

Universale solution for connection to communication-ports by PHLOX II

Input cable harness

PHLOX II

(ignition system on the engine)

GND

CAN -1

Power-supply

input

- BAT

+BAT

+24V

T. 20

T. 21

T. 7

Control-cabinet

H/A

L/B

GND

CAN -2 (is.)

T. 8

T. 9

T. 19

Bus

CAN

Bus

CAN or Modbus
