9 Inputs and outputs
54 PHLOX II Ignition Control System
Connection
name
Terminal
Configuration
parameters
Configuration
4806 DigCh2TriStatOrDigIn
If digital input (Par.
4799 = 0, Par. 4804 = 0,
Par. 4805 = 0)
0 = Normal digital input
1 = Tristate switch
4807 DigIn2HighOrLowSide
If digital / PWM input
(Par. 4799 = 0, Par. 4804
= 0, Par. 4805 =1 or Par.
4806 = 0)
0 = Low side input (Pull-
up activated)
1 = High side input
(Pull-down activated)
Table 14: PHLOX II: selectable inputs / outputs
Parameterising Example:
Port 1 is used as cam index output (for example to transmit the pick-up signal to
the Ariadne control unit). Port 2 is used as PWM input 2. The signal received is a
high-side signal.
Number Parameter Value Unit
4798 DigChannel1_CamIxOut 1
4799 DigChannel2_CamIxOut 0
4804 DigChannel2OutOrIn 0
4805 DigChannel2PWMOrDIO 1
4806 DigCh2TriStatOrDigIn 0
4807 DigIn2HighOrLowSide 1
