11 Commissioning
80 PHLOX II Ignition Control System
Camshaft index setup
Activate Index:
Par. 4005 = 1
Configure index pick-up type according to used pick-up:
Par. 4025 = 0 for Hall Pick-ups.
Par. 4025 = 1 for inductive (magnetic) pick-up.
Hall camshaft index pick-up setup
This paragraph concerns only Hall pick-ups
Configure index pick-up power supply according to pick-up specification:
Par. 4027 = 0 to setup a 12V pick-up power supply
Par. 4027 = 1 to setup a 5V pick-up power supply
Configure index pick-up signal output according to pick-up specification:
Par. 4028 = 0 for Heinzmann standard pick-up signal output (signal low when pick-up
over tooth, high when pick-up over gap)
Par. 4028 = 1 for inverted pick-up signal output (signal high when pick-up over tooth,
low when pick-up over gap)
Configure trigger edge for best timing:
The pick-up used determines whether the rising or falling edge should be used for opti-
mum ignition timing.
Par. 4029 = 0 for Heinzmann standard trigger edge (begin of tooth / gap)
Par. 4029 = 1 for inverted trigger flank (end of tooth / gap)
Inductive camshaft index pick-up setup
This paragraph concerns inductive pick-ups only
For inductive pick-ups, the trigger level is speed-dependent and can be setup with the help of a
curve (Par. 7720-7724, 7720-7724 or via the menu Graphic->Curve->Trigger-Level Inductive
Cam-Index). It is important to setup this curve properly according to the pick-up and measuring
