Heinzmann PHLOX II IC-08 User Manual

11 Commissioning
84 PHLOX II Ignition Control System
Figure 14: Inductive pick-ups
Configure the pick-up and index positions as following:
Par. 3 = α [°crank]
Par. 5 = β [°crank]
Ignition TDC of cylinder A1
Rotational direction of engine
Ignition TDC of cylinder A1
Rotational direction of engine
α = Distance of
sensor to gap
Ignition TDC of cylinder A1
Rotational direction of engine
β = Distance of
sensor to gap
α = Distance of
sensor to gap
Inductive Pick-ups
